Frame: FORM™ Alloy | Full Sealed Cartridge Bearings | BSA Bottom Bracket | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 160mm Travel. FORM™ Alloy Rear Triangle
Fork:Fox 38 Float EVOL GRIP Performance Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset
Front Travel:170
Rear Shock:Fox Float X Performance | Sealed Bearing Eyelet | 40x10mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ
Rear Travel:160
Headset:FSA ZS56|66 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
Stem:Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm
Handelbar:Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
Grips:ODI Elite Pro Lock On
Brakes:Shimano SLX Trail 4 Piston | Metal Pads
Shifters:Shimano SLX
Rear Derailleur:Shimano XT
Cranks & Chainring:Race Face Aeffect Cinch | 32T | 24mm Spindle | SM = 165mm | MD - XL = 170mm
Bottom Bracket:Shimano Threaded BBMT501-B
Cassette:Shimano Deore 10-51T 12spd
Chain:Shimano M6100
Front Hub:Rocky Mountain SL Sealed Boost 15mm
Rear Hub:Shimano XT Boost 148mm
Spokes:DT Swiss Competition 2.0/1.8/2.0
Rims:WTB ST i30 TCS 2.0 Tubeless | 32H / Tubeless Ready - Tape / Valves Incl
Tires:F: Maxxis Assegai 2.5 WT 3C MaxxGrip EXO+ Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready
Seatpost:X Fusion Manic Alloy 30.9mm | Shimano MT500 Remote | SM = 150mm | MD = 170mm | LG - XL = 200mm
Saddle:WTB Volt Race 142
